SITRANS TS300

SITRANS TS300 was designed for use in hygienic applications. The advantages of the clamp-on technology come into play particularly with small pipe diameters: no welding and welding validation, no disruption to the process, piggability maintained, easy disassembly for recalibration and all this with a measurement accuracy that is comparable to that of the built-in sensors.

• Hygienic - Sensor design according to EHEDG recommendations
• Available - Inserts exchangeable
• Low costs, many advantages – Low cost of ownership for installation, validation and recalibration; no process disturbance

Detail

• Output direct sensor signal
• Max. operation temperature Pt 100 Basic: - 50 ... +400 °C (-58 ... +752 °F)
• measuring point Pt 100 Extended: -196 ... +600 °C (-320.8 ... +1 112 °F)
• cable end Thermo couple -40 ... +1250°C (-40 ... +2 282 °F) (depending on type) -40 ... +80 °C (-40 … +176 °F)
• Ingress protection IP54 (depending on connector type)
• Approvals ATEX, IECEx, CSA, cCSAus, NEPSI, EAC, EACEx
• Output direct sensor signal 4…20 mA (TH100/TH200) HART (TH300) PA (TH400) FF (TH400)
• Max. operation temperature
• - In the pipe: –30…+300 °C
• - Clamp-on: –20…+160 °C
• Ingress Protection IP65 (IP54 for some type of connection heads)
