Azbil Smart HART Modem Model AZ-1SHM

Quick Change Pressure Modules (30 seconds)

Additel's built-in pressure control modules can be installed or replaced within 30 seconds or less. Simply open the upeer edge of the cabin to open.  As the door opens, the controller will automatically release pressure, providing the safe removal and installation of the ADT151 modules.  Additel offers five different pressure ranges for the ADT793 controller.  Select between 1000 bar (15000 psi), 700 bar (10000 psi), 400 bar (6000 psi), 350 bar (5000 psi) or 200 bar (3000 psi) with the variety of accuracies to meet application requriements.

A Singular Pressure Module Design with a Wide Range of Capabilities

Additel’s 151 pressure modules have been designed with flexibility and efficiency in mind and can easily be swapped out as needed to meet changing needs and workloads.Higher pressure ADT151 modules cover two separate pressure ranges and come with individual calibrations for each range. This allows for each module to accuracy cover a wide range or pressure workloads. Also, each ADT151 is available in (3) different accuracy levels (0.02% FS, 0.01% FS and 0.01% of reading to meet the demanding needs of our customers. modular configuration provides users with the greatest flexibility.

20% Pressure Step within 30 Seconds

In the process of efficient and fast-paced production line testing, verification and calibration, users have strict requirements on the speed of pressure controllers. ADT793 adopts professional control technology to effectively improve control rate and stability: control response time (typical) ≤30 seconds, control stability (typical) ≤±(0.003~0.005)%FS, see specifications for more details.

External Reservoir Support

The ADT793 has been designed to support a method of contamination prevention in which the controller only draws in clean fluid during each
pressure cycle and purges potentially polluted fluid externally during each cycle to prevent cross contamination between the controller and units under test (UUT’s).

Contamination Prevention System (CPS) Prolongs the Maintenance of the Controller

Calibration of DUT’s (devices under test) often introduces contaminates to a calibration system. Contaminates can cause restrictions in valves, lines and filters. Additel has included a turn-key solution with the ADT793 to help reduce these concerns and improve durability and dependability when calibrating customers devices. The use of an automatic fluid exhaust system and integration firmware to allow for purges between pressure cycles to further reduce the possibility of introducing contaminates into the system.
